Microwave Motion Sensor

Ceiling Surface Mounted 2.4GHz millimeter wave radar radar real presence sensor (PS-RS87)

Ceiling Surface Mounted 2.4GHz millimeter wave radar radar real presence sensor (PS-RS87)

Model NO.: PS-RS87
Function: 2.4GHz millimeter wave radar radar real presence sensor
Ceiling surface mounted
Long detect range
INQUIRY

Techncial data:

1) Detection Angle: 360°
2) Detection Range: Max 4-5m(radius) movement signal such as hand moving, shake head.
2-3m(radius) breathe signal
3) Time Setting: 10Sec/1Min/5Min/15Min (adjustable)
4) Power Source: 220~240V/AC 50/60Hz
5) Rated Load: Max.800W (incandescent lamp),400W (energy-saving lamp)
6) Ambient Light: <10/30/100Lux/Day (adjustable)
7) IP20
8) Product Size:108*25mm
