Presence Sensor

Real Presence Sensor Breathe Sensor(PS-RS94)

Model NO.: PS-RS94
Power supply: 220-240VAC; 100-130VAC
Size: 68*63.75MM
Detection Range:1.5-4m (linear distance between probe and human body) (adjustable)
INQUIRY

Specification:

1) Power supply voltage: 100-240VAC
2) Power frequency: 50/60Hz
3) Transmit power: <0.2mW
4) Rated load:
-800W Max.tungsten(220-240VAC)
-200W Max.fluorescent & LED (220-240VAC )
-400W Max.tungsten (100-130VAC)
-100W Max.fluorescent & LED (100-130VAC)
5) Protection level: IP20, Class 2
6) Installation sit: indoor, ceiling, wall
7) HF system: 24GHz FMCW wave, ISM band
8) Detection Angle: 360°
9) Detection distance: 1.5-4m (linear distance between probe and
human body) (adjustable)
10) Delay setting: 5sec-3min, (adjustable)
11) Light control illumination: 2-2000LUX, (adjustable)
12) Power consumption: <0.3W
13) Operating temperature: -15°C~+70°C
